Aiphone LE-SSV Sub Station with Built-In Color Pinhole Camera for AP-M, LAF-C, LDF-C, LEF, LEM, MP-S Master Stations

BH #AILESSV • MFR #LE-SSV
Print
Aiphone LE-SSV Sub Station with Built-In Color Pinhole Camera for AP-M, LAF-C, LDF-C, LEF, LEM, MP-S Master Stations
No Longer Available
No Store Display
Ask an Expert
800-606-6969

Aiphone LE-SSV Overview

The Aiphone LE-SSV Sub Station with Built-In Color Pinhole Camera connects to the LAF-C, LEF, LEM, AP-M, or MP-S Master Stations. The call tone rings at the master station as long as the call button is held down. The communication is hands-free at the sub station end, while at the master end, it is push-to-talk, release-to-listen.

The LE-SSV Sub Station is constructed with 12-gauge stainless steel and has a standalone color camera built-in. The unit can be either flush mounted using a 2-gang box, or surface mounted using the SBX-2G Surface Mount Enclosure. The sub station unit includes a 12VDC power transformer for the camera, tamper-proof screws, and a tool for installation. The built-in camera features a 1/3" CCD image sensor and a 4.3mm, cone pinhole lens. This sub station is IP65 & IK08 rated.

For use with LAF-C, LEF, LDF-C, LEM, AP-M, MP-S Master Stations
Built-in color pinhole camera
Weather and vandal-resistant (IP65 & IK08)
Stainless-steel construction
2-gang electric box mountable

Aiphone LE-SSV Specs

For Use with
LAF-C, LEF, LDF-C, LEM, AP-M, MP-S Master Stations
Power Source
Supplied by master station
Speaker
20 Ω, 4 W, water-proof and puncture resistant
Button
SPST call button, momentary activation. Limited stop button
Call Alerts
Call tone rings at master as long as button is held down. LED will remain lit for approximately 20 sec (LEF, LEM-3, MP-3S, AP-5/10M Entry Security Systems only)
Call tone only on LEM-1DL, LEM-1, and MP-1S Access Sentry Systems
Communication
Hands free at sub station. Master is push-to-talk, release-to-listen
Camera Output
75 Ω, 1 Vpp, NTSC, DC-coupled
Iris Control
Auto
Minimum Illumination
1.0 lux
Image Sensor
1/3" CCD
Focal Length
4.3 mm, Cone Pinhole Lens (78°)
Effective Pixels (H x V)
510 x 492, NTSC
Power Source
For Camera: 12 VDC, 100 mA (via included power supply)
MTBF
80,000 hours (Mean Time Before Failure)
Wiring
Audio Wiring:
2 conductors in a 1-master LEF, MP-S, or AP-M system
3 conductors in a multi-master LEF system
Shielded cable is recommended
Use Aiphone 822202 wire for LEM or MP-S; 822202 or 822203 for LEF; 832202 for AP-M systems

Video Wiring: Independent BNC connection from substation pigtail to destination video device
Mounting
Flush mount into a 2-gang box (minimum 2.5" (6.3 cm) depth) or surface mount into SBX-2G (sold separately)
Distance
Audio Wiring Distance:
For LEM, LEF, LAF-C, LDF-C:
Door / Sub to Farthest Master: 650.0' (198.1 m) (22 AWG), 1,600.0' (487.7 m) (18 AWG)

For AP-M:
Doors / Subs / Horns to Master: 490.0' (149.3 m) (22AWG), 1,200.0' (365.8 m) (18AWG)

For MP-S:
Doors / Subs/ Horns to Master: 330.0' (100.6 m) (22AWG), 720' (219.4 m) (18AWG)
Mounting
Flush mountable using a 2-gang box
Surface mountable using the SBX-2G Mount Enclosure. (Both mounts sold separately)
Termination
Color-coded prewired pigtails
Red Wire: "1"; Black Wire: "E"; Blue Wire: negative; Red Connector: 12 VDC power; Yellow Connector: 75 Ω / 1 Vpp video output (BNC)
Operating Temperature
14 to 140°F (-10 to 60°C)
Material
Faceplate: 12-gauge stainless steel
Dimensions
LE-SSV Alone: 4.7 x 4.7 x 2.0" (11.9 x 11.9 x 5.1 cm)
With SBX-2G: 4.7 x 4.9 x 3.6" (11.9 x 12.4 x 9.1 cm) (Top)
2.4" (6.1 cm) (Bottom)
Speaker Diameter: 2.4" (6.1 cm)
Weight
2.0 lb (0.9 kg)
Speaker Magnet: 2.4 oz (68.0 g)
