| Display | 8" / 20.3 cm color LCD, TFT display, 800 × 600 pixels, 65,535 colors |
| Bandwidth | 30 MHz |
| Sample Rate | 500 MS/sec |
| Scale | Horizontal: 4 ns - 100 s/div, step by 1-2-4 |
| Rise Time | 11 ns or less |
| Channels | 2 + 1 (external) |
| Input Impedance | 1 MOhms ± 2%, in parallel with 15 ± 5 pF |
| Channel Isolation | 50 Hz: 100:1
10 MHz: 40:1 |
| Input Voltage | Max. 400 V (DC+AC, pk - pk) |
| Gain Accuracy | ±3% |
| Record Length | 10 K |
| DC Accuracy | 16 or more ±(3% reading + 0.05 div) for △V, average |
| Attenuation | 1x, 10x, 100x, 1000x |
| LF Response | ≥10 Hz (at input, AC coupling, -3 dB) |
| Relays | Sample Rate / Relay Time Accuracy: ±100 ppm |
| Interpolation | sin (x) / x |
| Interval Accuracy | Single: ±(1 interval time + 100 ppm x reading + 0.6 ns)
Average >16: ±(1 interval time + 100 ppm x reading + 0.4 ns)
(At full bandwidth) |
| Coupling | Input: DC, AC, and GND |
| Vertical Resolution | A/D: 8-bit (two channels simultaneously) |
| Vertical Sensitivity | 5 mV - 10 V/div (at input) |
| Triggers | Type: Edge, Pulse, Video, Slope, Alternate
Mode: Auto, Normal, Single
Level: ±6 divisions from screen center |
| Frequency | Line/Field: NTSC, PAL, and SECAM standards |
| Measurement | Cursor: △V and △T between cursors
Automatic: Vpp, Vavg, RMS, frequency, period, Vmax, Vmin, Vtop, Vbase, width, overshoot, pre-shoot, rise time, fall time, +width, -width, +duty, -duty, delay A→B , delay A→B |
| Waveform | Math: ＋, －, ×, ÷, invert, FFT
Storage: 15 waveforms |
| Lissajous Function | Figure Bandwidth: Full bandwidth
Figure Phase Difference: ±3° |
| Communication Interface | USB host, USB device, pass/fail, LAN, VGA |
| Power Supply | 100 to 240 VAC, 50/60 Hz, CAT Ⅱ |
| Maximum Power Consumption | 18 W |
| Fuse | 2 A, T class, 250 V |
| Dimensions | 13.7 x 6.7 x 3.1" / 34.8 x 17.0 x 7.8 cm |
| Weight | 3.3 lb / 1.5 kg |
