Hitachi Z-HD5000 HDTV Camera Studio Package with Fujinon XA20sx8.5BERM HDTV lens

BH #KOZHD5000ST2 • MFR #Z-HD5000-ST2
Print
Authorized Dealer
Hitachi Z-HD5000 HDTV Camera Studio Package with Fujinon XA20sx8.5BERM HDTV lens
No Longer Available
No Store Display
Ask an Expert
212-444-6615

Hitachi Z-HD5000 Overview

The Camera Package from Hitachi includes the Z-HD5000 camera head, TA-Z3 tripod adapter, VF-701HDA 7" HDTV color LCD viewfinder with AT-500 mount, CU-HD500 camera control unit, CA-HF1000 camera head adapter, RU-1000VR small remote control with 30' cable, Fujinon XA20sx8.5BERM HDTV lens with 2x range extender, and Fujinon MS-01 lens control kit.

Hitachi Z-HD5000 Specs

Camera
Imaging Device
2/3", 16:9, 1 MP Super-Advanced micro-lens IT-CCD (3X - RGB)
TV System
1920 x 1080 / 59.94i
Optical System
F1.4 prism
Optical Filter
1 x manual filter wheel w/4 filter positions
Clear, Cross, 1/16ND, 1/64ND
ECC (Electronic Color Corrector) with 5 settings
3200K, 4300K, 5600K, 6300K, 8000K
Sensitivity
F10 @ 2000 lux, 3200K, 89.9% reflectance
Signal to Noise Ratio
58 dB
Horizontal Resolution
> 800 TVL (1080i)
Registration
Overall 0.05% (excluding lens limitations)
Gain Selection
L (Low): -3, 0 dB
M (Medium): 0, +3, +6, +9, +12, +15, +18, +21 dB
H (High): +3, +6, +9, +12, +15, +18, +21, +24 dB
Electronic Shutter
1/59.94 sec Off, 1/100, 1/250, 1/500, 1/1000, 1/2000, AES, CC Frame
Power Consumption
16 W head only (without VF, lens)
Operating Temperature
14 to 113°F (-10 to 45°C)
Input & Output
1 x BNC HD-SDI VF out (Character On/Off) or HD-SDI RET out
4-pin Multi connector for remote control panel
20-pin Multi VF connector
3-pin XLR MIC-1 connector
SD memory card slot
Dimensions
5.2 x 7.5 x 10.3" (133 x 191 x 262 mm)
Weight
4.8 lb (2.2 kg)
Viewfinder
Screen Size
7" (178 mm)
Resolution (H x V)
1280 x 800
Dot Pitch
0.117 x 0.117 mm
Aspect Ratio
16:9 / 4:3 switchable
Color Depth
8-bit, 16.7 million colors
Brightness
400 cd/m2
Contrast
800:1
Response Time
12 ms
Viewing Angle
178°/178°
Voltage Input
12 VDC, VF main line power supply
Power Consumption
<11 W
Dimensions
8.14 x 5.94 x 2.3" (207 x 151 x 60 mm)
Weight
<2.2 lb (<1 kg)
Camera Control Unit (CCU)
Genlock
BNC, B-BST 0.45 V p-p/75 Ohms (loop through)
HDTV tri-level sync 0.60 V p-p/75 Q (loop through)
Digital Return 1/2
BNC, HD-SDI, or SD-SDI
Prompter Input
BNC, VS, or VBS 1.0 V p-p/75 Ohms (loop through)
Intercom
5-pin XLR, -60 dBm
Communication
1 x D-sub 25-pin
Intercom: 0 dBm, 600 Ohms / 4-Wire, 0 dBu, or -15 dBu, 200 Ohms with 2-wires
PGM: 0 dBm, 600 Ohms
R/G TALLY: Contact or DC supply
Digital Output: 2 x BNC, HD-SDI (embedded audio available), 4 x BNC, HD-SDI or SD-SDI selectable (embedded audio available), HD-SDI or SD-SDI selectable PIX (embedded audio available)
Connectors
Mic Output 1: 1 x XLR, 3-pin, 0 dBm / 600 Ohms
Mic Output 2: 1 x XLR, 3-pin, 0 dBm / 600 Ohms
Intercom (Headset): 1 x XLR, 5-pin, 0 dBu Maximum 15 dB
Remote 1: 1 x 4-pin, 1.5 V p-p
Remote 2: 1 x 4-pin, 1.5 V p-p
RS-232C: 1 x D-sub 9-pin 9600 band
Mic Remote: 1 x D-sub 15-pin, Mic 1.2 gain
TALLY OUT (R/G Tally): 1 x D-sub 9-pin, Contact 24 VDC 10 mA
WFM Control: 1 x D-sub 15-pin, WFM 0-7, 0/5 V
Maximum Cable Distance
3280' (1000 m) with CCU power
Power Supply Voltage
117 VAC @ 60 Hz
Operating Temperature
32 to 104°F (0 to 40°C)
Weight
19.8 lb (9 kg)
Camera Adapter
CCU
1 x Type HFOC female connector (LEMO/Tajimi-type)
SMPTE-304M-type
Video Transmitter
Fully digital, bi-directional, 10-bit, 4:2:2 sampling, SMPTE-274M
Intercom
2 x channel, 5-pin each XLR, channel selection, Mic on/off, volume
Audio
2 x PGM audio level controls with Channel 1 and 2 intercom mix
Power Output
Teleprompter: 1 x 5-pin, 230 VAC, 60 to 100 W, external prompter Tally drive out (depending on configuration accessories)
Microphones
Channel 1 & 2 Line or MIC level select (Menu), with phantom power on/off
Switcher
Return / Aux: 2-channel, 4-input remote AUX/VF video select connector (RET control)
Video Input & Outputs
2 x HD-SDI out, 1 x SD analog teleprompter out switchable with, 1 x Genlock in (Tri-level)
Other I/O
1 x 29-pin (for SA-1000 cable-less interface)
1 x 4-pin script lamp 12 VDC (1.0 A maximum)
1 x 5-pin VF AUX return (for use in cranes or extended Head/VF configurations)
1 x 4-pin XLR, 12 VDC, power input
Weight
4.8 lb (2.2 kg)
Remote Control
Power Input
12 VDC
Operational Temperature
32 to 104°F (0 to 40°C)
Dimensions
VR Knob: 4.56 x 7.16 x 2.4" (116 x 182 x 60 mm)
Weight
3.3 lb (1.5 kg)
Lens
Camera Format
2/3"
Focal Length
1x: 8.5 to 170mm
2x: 17 to 340mm
Zoom Range
20x
Maximum Relative Aperture
1:1.8 (8.5 to 113 mm)
1:2.7 (170 mm)
M.O.D. from Image Plane
3.6' (1.1 m)
M.O.D. from Front of Lens
2.9' (0.9 m)
Object Dimensions at M.O.D. (16:9)
1x
8.5mm: 35.8 x 20.1"(910 x 511 mm)
170mm: 1.8 x 1.0" (47 x 26 mm)

2x
17mm: 18.5 x 10.4" (469 x 264 mm)
340mm: 0.9 x 0.5" (24 x 13 mm)
Angular Field of View (16:9)
1x
8.5mm: 58°51' x 35°11'
170mm: 3°14' x 1°49'

2x
17mm: 31°30' × 18°01'
340mm : 1°37' × 0°54'
Filter Thread
M82 x 0.75
Dimensions
3.3 x 7.12" (85 x 180.8 mm)
Weight
3.48 lb (1.58 kg) lens hood included
