| Frequency Response | 50 Hz - 20 kHz, ±3 dB (1/3 rated output)
800 Hz - 2.8 kHz (UL2572)
400 Hz - 4 kHz (CAN/ULC-S576) |
| Distortion | 0.7% or less (at rated output, 1 kHz) |
| S/N Ratio | 85 dB or more |
| Audio Characteristics | Sampling Frequency: 48 kHz
A/D D/A Converter: 24 bit |
| Inputs | Input 1 - 3: Combo XLR-1/4" / 6.3 mm jack, -50 dB (Mic) / -10 dB (Line) (changeable), 600 Ohms, electronically balanced
Input 4: 14-pin removable terminal block, -50 dB (Mic) / -10 dB (Line) (changeable), 600 Ohms, electronically balanced
BGM 1 - 2: RCA pin jack, -10 dB, 10 kOhms, unbalanced
External AMP Input: 14-pin removable terminal block, 70 V line |
| Outputs | Speaker Output 1 - 2: Max 240 W per output
Speaker Output 3 - 6: Max 100 W per output
Speaker Output 1 - 6: 14-pin removable terminal block, total within rated output
Recommended Minimum Load: 245 Ohms (20 W) at 70 V for speaker line failure detection
Direct Output: 16-pin removable terminal block, direct output from internal or external amplifier
Recording Output BGM/Paging: RCA pin jack, 0 dB, 10 kOhms
Ground Fault Detection: 0 Ohms
Wire to Wire Fault Detection: 0 Ohms |
| VM-Link Connectors | Input: RJ45 female, for VM-3240VA
Output: RJ45 female for VM-3240E
Link Cable: Category 5 shielded twisted-pair straight cable (Cat5-STP) |
| Link | RM Link
Input 1 - 2: Connection to RM-300MF/200M Remote Microphone, RJ45 female connector
Maximum Distance: Total 2625' / 800 m between this unit and remote microphones
Link Cable: Category 5 shielded twisted-pair straight cable (Cat5-STP)
VM Link
Output: Audio and control link to a VM-3240E extension amplifier, RJ45 female connector
Link Cable: Category 5 shielded twisted-pair straight cable (Cat5-STP)
DS Link
To Local VX-2000DS: RJ45 female connector
Link Cable: Category 5 shielded twisted-pair straight cable (Cat5-STP) |
| Network I/F | 10BASE-T/100BASE-TX (automatic negotiation), RJ45 female connector
Maximum Distance: 328' / 100 m between this unit and a switching hub
Link Cable: Category 5 shielded twisted-pair straight cable (Cat5-STP) |
| Control | General Control
Input 1 - 8: No-voltage make contact input, open voltage: 24 VDC
Short-Circuit Current: 14-pin removable terminal block, 2 mA or less
Output 1 - 8: Isolated open collector output, withstand voltage: 30 VDC
Operating Current: 14-pin removable terminal block, 10 mA or less
Emergency Control
Input 1 - 5: No-voltage make contact input, open voltage: 24 VDC
Short-Circuit Current: RJ45 female connector, 2 mA or less
Input 6: Isolated voltage input, inactive: -24 V, ±20%
Active: RJ45 female connector, +24 V, ±20%
Status Output: Relay contact output, withstand voltage: 40 VDC
Operating Current: RJ45 female connector, 2 to 300 mA |
| Power Input/Output | Power Input: From VX-2000DS only (operating range: 20 to 40 VDC)
PS Output: 28 VDC / 18 A
M4 screw terminal, distance between barriers: 11 mm |
| Power Source | 120 VAC, 60 Hz |
| Power Consumption | 690 VA (at rated output), 260 W (UL60065), 63 W (no signal) |
| Rated Output Power | 240 W, 21 Ohms (UL60065)
200 W, 25 Ohms (UL2572)
200 W, 25 Ohms (CAN/ULC-S576 with separate UPS)
100 W, 50 Ohms (CAN/ULC-S576)
Total amplifier output (1 - 6 and Direct Output) |
| DC Output | 22 VDC special application, maximum current 0.3 A (for RM-200M only) |
| Operating temperature | 32 to 120°F / 0 to 49°C |
| Operating Humidity | 5 to 95% RH (no condensation) |
| Finish | Panel: Aluminum, hair-line, black
Case: Surface-treated steel plate, black paint |
| Dimensions | 18.98 x 5.22 x 16.98" / 48.2 x 13.3 x 43.1 cm |
| Weight | 36.38 lb / 16.5 kg |
