| Basic Specifications |
|
| Screen Size | 80" (diagonal) |
| Bezel Width | Horizontal upper: 3-15/16" (100 mm)
Horizontal lower: 1-31/32 (50 mm)
Vertical: 1-31/32 (50 mm) |
| Native Resolution | 1920 x 1080 |
| Brightness | 300 cd/m2 |
| Landscape&Portrait Mode Operation | Landscape compatible |
| 24/7 Continuous Operation | Yes |
| Fan | No (fanless architecture) |
| Audio | 7W + 7W stereo with built in speakers |
| LCD type | UV2A LCD |
| Number of Colors | 1.06 Billion |
| Contrast Ratio | 3000:1 |
| Aspect Ratio | 16:9 |
| Viewing Area (HxV) | 160º H x 160º V (CR>/=10) |
| Active Screen Area | 69-3/4 x 39-1/4" (WxH) |
| Frame Rate | 60 Hz |
| Pixel Pitch | 0.923 x 0.923 mm (HxV) |
| Video System | NTSC (3.58 MHz; 4.43 MHz), PAL, PAL60, SECAM |
| Computer Input - Video | Analog RGB (0.7 Vp-p) [75-ohm], Digital (conforms to DVI 1.0 standards) |
| Computer Input - Synchronization | Horizontal / Vertical separation (TTL: positive/negative), Sync on green, composite sync (TTL: positive/negative) |
| Computer Input - Plug & Play | VESA DDC2B |
| Power Management | VESA DPMS, DVI DMPM |
| Response Time | 6 ms (gray to gray, avg) |
| Terminals |
|
| PC/AV Video Input | Analog mini D-sub 15-pin. DVI-D 24-pin HDCP Compatible (requires optional PN-ZB01); Analog 5-BNC (requires optional PN-ZB01; analog RGB and component are menu selectable). |
| PC/AV Audio Input | 3.5mm mini stereo jack |
| Video Inputs | Composite Video - BNC (requires optional PN-ZB01) |
| S-Video Input | 5-Pin DIN (requires optional PN-ZB01) |
| Component Video | BNC (Y, Cb/Pb,Cr/Pr) (requires optional PN-ZB01; component video and analog RGB are menu selectable). |
| HDMI | Yes - compatible for both PC and AV components |
| Audio | (AV) RCA pin (L/R) x 2 (requires optional PN-ZB01) |
| Computer Outputs | DVI-D 24-pin (HDCP compatible, PC/AV signal; requires optional PN-ZB01) |
| Audio Line Output | RCA pin (L/R) - selectable fixed or variable line output |
| Speaker Output | 7W + 7W Stereo (6-ohms; requires optional PN-ZB01) |
| LAN Port | RJ-45 (requires optional PN-ZB01) |
| RS-232C | D-sub 9-pin |
| Power Output Connector | Yes - 19V |
| Functions |
|
| Screen Adjustment | Auto (Clock, Phase, H-POS/V-POS) / Manual |
| Gain Control | Auto (Black level, Contrast) / Manual |
| Digital Scaling (expansion) | Yes (VGA/SVGA/XGA/SXGA -> 1920 x 1080) |
| Digital Scaling (compression) | 1920 x 1200, 1600 x 1200 |
| Main User Adjustments | Clock, Phase, H-POS/V-POS, Black level, Contrast; Color temp (18 steps preset + 3200K/5600K/9300K + User setting); Color mode (Standard/sRGB/Vivid); Gamma (1.8/2.0/2.2/2.4/User setting); Brightness, Volume, Audio (Treble/Bass/Balance), OSD-POS; Picture Adjustment (Tint, Color Intensity) [PC/AV mode]; R/G/B/Y/M/C independent adjustment [AV mode] |
| Information | Model No., Serial No. etc. |
| Real Time Clock Setting | Yes |
| Scheduling Function | Yes (time, day of the week) |
| All Reset | Yes |
| Reset | Screen/Picture/Audio adjustment setting, etc. |
| Adjustment Lock | Yes (Incl. Power button) |
| Daisy Chain (DVI-D) | Optional (PN-ZB01): max. 5 units (HDCP compliant) |
| Enlarge | No |
| Frame Width Adjustment | Yes |
| PinP / PbyP | Yes (PinP : 12 steps) |
| Power On Delay | 1-60 seconds (with 1 second interval) |
| Audio Input Change | Yes |
| Picture Flip | No |
| Self Adjust | Yes (PC Analog Input) |
| Log Save / Output | Yes |
| Temperature Control | Yes |
| Hardware Diagnosis | Yes |
| Monitor Control Software Support | Yes |
| Web Browser Setting (LAN) | Optional (PN-ZB01) |
| Email Notification | Optional (PN-ZB01) |
| SNMP | Optional (PN-ZB01) |
| Overscan Setting (AV Input) | Yes |
| Image Size Change Function | Yes |
| Resolution Change Function (PC analog) | Yes |
| RS-232C Communication Speed Change | Yes |
| Stereo Audio to Monaural | Yes |
| Audio Input per image input | Yes |
| Internal/External Speaker Select | Optional (PN-ZB01) |
| Power |
|
| Power Consumption | 260W Max. (with optional PN-ZB01 attached) |
| Standby Power Consumption | 1.0W |
| Power Source | 100 - 240V AC, 50/60 Hz |
| Additional Specifications |
|
| Tuner | None |
| Operating Temperature | 41 ~ 95ºF (5 ~ 35ºC) |
| Operating Humidity | 20% to 80% RH (no condensation) |
| Storage Temperature | -4 ~ 140ºF (-20 ~ 60ºC) |
| Limited Warranty and Service | 3-Year on-site. Covers parts, labor and backlight in landscape mode operation. |
| Regulatory Approvals | UL 60950, FCC Class A |
| ENERGY STAR Qualified | N/A |
| Mounting Configuration | VESA (6 points), 7.875" pitch (200mm), M6 screws or VESA (4 points), 7.875" pitch (200mm), M6 screw |
| Remote Control | Yes (wireless remote plus wired RJ-45 and RS-232C) (RJ-45 requires optional PN-ZB01) |
| General |
|
| Dimensions | 74 x 45-9/16 x 5-5/16" (188.0 x 116.0 x 13.5 cm) |
| Weight | 225 lb (102 kg) (approximate) |
