| Camera |
|
| Image Sensor | 1/3 type MOS sensor |
| Effective Pixels | Approximately 3.1 MP |
| Scanning Mode | Progressive |
| Scanning Area (H x V) | 4.51 mm × 3.38 mm (3.187 x 1.125") |
| Minimum Illumination | Color: 1.5 lux (F2.4, Auto Slow Shutter: Off (1/30s), Gain: On (High))
Color: 0.1 lux (F2.4, Auto Slow Shutter: Maximum 16/30s, Gain: On (High))
B&W: 1.2 lux (F2.4, Auto Slow Shutter: Off (1/30s), Gain: On (High))
B&W: 0.08 lux (F2.4, Auto Slow Shutter: Off (16/30s), Gain: On (High)) |
| White Balance | AWC (2,000 to 10,000 K), ATW1 (2,700 to 6,000 K), ATW2 (2,000 to 6,000 K) |
| Light Control Mode | Indoor scene (50 Hz / 60 Hz) / ELC |
| Shutter Speed | With Super Dynamic On:
ELC (1/30 s)
With Super Dynamic Off:
ELC (1/30 s), ELC (3/100 s), ELC (3/120 s), ELC (2/100 s), ELC (2/120 s), ELC (1/100 s), ELC (1/120 s), ELC (1/250 s), ELC (1/500 s), ELC (1/1,000 s), ELC (1/2,000 s), ELC (1/4,000 s), ELC (1/10,000 s) |
| Super Dynamic | On / Off |
| Dynamic Range | 52 dB type (only at Super-Dynamic On) |
| Adaptive Black Stretch | On / Off (only at Super-Dynamic Off) |
| AGC (Automatic Gain Control) | On (High) / On (Mid) / On (Low) / Off |
| Electronic Sensitivity UP | Off (1/30 s), Maximum 2/30 s / 4/30 s / 6/30 s / 10/30 / 16/30 s |
| Day & Night | Electrical: Off / Auto |
| Digital Noise Reduction (DNR) | High / Low |
| Video Motion Detection | On / Off, 4 areas available |
| Video Analytics | Face Detection: Off / On / On with face frame display
However, face detection is not supported when Fisheye or Quad streams is selected for the image type. |
| Auto Mode | Auto pan / Preset sequence
Auto mode can only be used when the image type is Quad PTZ or Single PTZ. |
| Self Return | 10 s / 20 s / 30 s / 1 min / 2 min / 3 min / 5 min / 10 min / 20 min / 30 min / 60 min
Self return can only be used when the image type is Quad PTZ or Single PTZ. |
| Privacy Zone | On / Off (up to 4 zones available) |
| VIQS | On / Off (up to 2 areas available)
However, the VIQS function is not supported when Quad PTZ, Single PTZ or Quad streams are selected. |
| Camera Title (OSD) | Up to 20 characters (alphanumeric characters, marks), On / Off
However, you can specify characters to be displayed on each of the four screens when Quad streams are selected. |
| Lens |
|
| Focal Length | 0.837 mm |
| Angular Field of View | Horizontal: 182°, Vertical: 176° |
| Maximum Aperture Ratio | 1:2.4 (Fixed) |
| Focusing Range | 0.3 m to infinity |
| Browser GUI |
|
| Camera Control | Pan / Tilt / Digital Zoom, Preset, Auto Mode, Self Return, Fisheye Control, Brightness
AUX: On / Off |
| Display Mode | Spot, Quad: Image from 16 cameras can be displayed in 4 different Quad screens or 16 split screen (JPEG only). 20 characters camera title available. |
| Digital Zoom | 1x, 2x, 4x controlled by browser GUI (Quad PTZ or Single PTZ mode)
1x to 4x (Panorama, Double Panorama, 3M Fisheye mode) |
| Camera Title | Up to 20 alphanumeric characters |
| Clock Display | Time: 12 hours / 24 hours
Date: 5 formats on the browser, summer time (manual) |
| One Shot Capture | A still picture will be displayed on a newly opened window |
| Audio | Mic (Line) Input: On / Off Volume Adjustment: Low / Middle / High
Audio Output: On / Off Volume Adjustment: Low / Middle / High |
| SD Memory Data Download | Still or motion Images recorded in the SDXC / SDHC / SD memory card can be downloaded. |
| GUI/Setup Menu Language | English, Italian, French, German, Spanish, Russian, Chinese, and Japanese |
| System Log | Up to 100 (Internal), Up to 4,000 (SDXC / SDHC / SD memory when the recording format is set to JPEG) error logs |
| Supported OS | Microsoft Windows 7, Microsoft Windows Vista, and Microsoft Windows XP SP3 |
| Supported Web Browsers | Windows Internet Explorer 9.0 (32 bit), Windows Internet Explorer 8.0 (32 bit), Windows Internet Explorer 7.0 (32 bit), and Microsoft Internet Explorer 6.0 SP3 |
| Network |
|
| Network IF | 10 Base-T/100 Base-TX, female RJ45 connector |
| Image Resolution | 2M Panorama[16:9] / 2M Double Panorama [16:9]:
H.264(1): 1920 x 1080 / 640 x 360 / 320 x 180, up to 30 fps
H.264(2): 640 x 360 / 320 x 180, up to 30 fps
JPEG: 1920 x 1080 / 640 x 360 / 320 x 180, up to 30 fps
1M Panorama [16:9] / 1M Double Panorama [16:9]:
H.264(1): 1280 x 720 / 640 x 360 / 320 x 180, up to 30 fps
H.264(2): 640 x 360 / 320 x 180, up to 30 fps
JPEG: 1280 x 720 / 640 x 360 / 320 x 180, up to 30 fps
Panorama + Quad PTZ / Panorama + Single PTZ / Double Panorama + Quad PTZ / Double Panorama + Single PTZ:
When using distribution of Panorama or Double Panorama:
H.264 (1): 1920 x 1080 / 640 x 360 / 320 x 180, up to 15 fps
JPEG: 1920 x 1080 / 640 x 360 / 320 x 180, up to 15 fps
When using distribution of Quad PTZ or Single PTZ:
H.264 (2): 1280 x 960 /640 x 480 / 320 x 240, up to 15 fps
JPEG: 1280 x 960 / 640 x 480 / 320 x 240, up to 15 fps
VGA Quad streams:
Channel 1 to channel 4, 640 x 480 maximum 30 fps
* Only for H.264 images
* There are specification limitations such as the SD memory card function being unavailable
3 M Fisheye [4:3]:
H.264(1): 1280 x 960, up to 15 fps
JPEG: 2048 x 1536, up to 15 fps |
| Total Bit Rate | 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 2,048 / 4,096 / 8,192 kbps / Unlimited |
| Supported Protocols | IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, RTP, FTP, SMTP, DNS, NTP, SNMP, DHCPv6, MLD, ICMP, ARP
IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP,FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP |
| FTP Client | Alarm image transmission, FTP periodic transmission
(When the FTP transmission fails, backup on an optional SD memory card is available) |
| Number of Simultaneous Users | Up to 14 users (depends on network conditions) |
| Memory Card | SDXC / SDHC / SD (Option):
Manufactured by Panasonic:
SDXC memory card: 64 GB
SDHC memory card: 4 GB, 8 GB, 16 GB, 32 GB
SD memory card: 1 GB, 2 GB
(except miniSD card and microSD card) |
| Face Detection | On / On (with XML notification)
3 M Fisheye [4:3], 1.3 M Fisheye [4:3], and VGA Quad streams modes cannot use the Face Detection function |
| Safety/EMC Standard | UL (UL60950-1), FCC (Part15 Class A), C-UL (CAN / CSA C22.2 No.60950-1), DOC(ICES003 Class A) |
| Power | Power Source and Power Consumption:
12 VDC, PoE (IEEE802.3af compliant)
12 V DC: 540 mA / 6.5 W (For UL-listed model(s), only connect 12 VDC Class 2 power supply)
PoE 48 V: 125 mA / 6.0 W (Class 2 devices) |
| Application | Railway: EN50155, EN50121 |
| Dimensions | Main Body: 6.1 x 2" (154 x 50.5 mm)
With Mount Bracket: 6.5 x 3.5" (164 x 88 mm)
With Base Cover Fixing Screw: 7.5 x 3.5" (191.5 x 88 mm) |
| Mass | With Bracket and Camera Attachment: 2.43 lb (1.1 kg) |
