| HD-SDI Input | Streaming Only: 9
With SDI or HDMI Output: 8 |
| Embedded Audio Input | 9 Stereo or 72 Mono inputs |
| Audio Monitoring | For 1/8": 1 |
| Inputs | 1 x HDMI input
1 x Composite (BNC) input
1 x S-VIDEO input
1 x Component input
4 x Analog audio (1/4") input
2 x AES/EBU input |
| Outputs | 1 x HDMI output
1 x Standard definition SDI output
1 x Composite (BNC) output
1 x S-VIDEO output
1 x Component output
1 x Analog audio (1/4") output
2 x AES/EBU output
2 x Additional AES/EBU or analog audio output |
| Media Sources | 6 integrated digital media sources for video and graphics playback
2 DDRs (video clip playback with built-in transcoder), 2 GFX (graphics), 2 color bars/background color |
| Built-In Multiview | On-screen full field rate multiview of all live inputs, Preview, Program Out, 2 GFX, and 2 DDR, Audio PPM overlay with peak hold feature on all inputs and outputs. Resizable layout allowing hiding of all controls to maximize multi-view screens |
| Video Switcher/Mixer | 1 x M/E (Mixer & Effects Bank) with no upstream keyer
Transitions: SMPTE Wipes, Cut & Fade (Auto transition with adjustable duration in frames, manual via on-screen T-BAR or keyboard shortcuts) |
| Graphics Downstream Key | 2 x Graphics DSK (downstream key) channels
One channel for GFX1 and one channel for GFX2
Independent or locked transition controls (fade/cut)
Preview on multi-view |
| Graphics & Titling | Load JPG or PNG files (full transparency support with PNG files)
Add text (set position/font/size/color) over any loaded image file within the GFX1 or GFX2 |
| Video Clip Playback | For 2 Media Players:
Eject/Load clip
PlayPause/stop
Audio/Video Scrubber
Timecode indicator
Seek to timecode
Mark in/Mark out
Loop
Auto-play on transition |
| Recording | AVI MJPEG with uncompressed audio. Interlacing and timecode support
Full compatibility with Blackmagic Design Media Express and Adobe Premiere |
| Recording Capacity | Approximately 40 hours at 1080i (Using 2 TB built-in Hard Drive with recorder set to record at 100 Mb/s for MJPEG and AVI) |
| Live Streaming | HD live streaming via Gigabit/100/10 built-in Ethernet
Presets in up to HD 720p
Multiple simultaneous Bit-Rates
Including mobile quality for playback over 3G on mobile devices (iPhone/Android)
Integrated live streaming to Livestream or any other RTMP compatible service including Ustream, YouTube Live, Akamai, Wowza media server |
| Audio Mixing | Integrated multi-channel audio mixer for internal and external audio sources, outputs, stream, and headphones
Incorporated video switcher follow feature with audio cross fade support when fading two video sources |
| Supported Formats | HD: 720p50, 720p59.94, 720p60, 1080PsF23.98, 1080p23.98, 1080PsF24, 1080p24, 1080PsF25, 1080p25, 1080PsF29.97, 1080p29.97, 1080PsF30, 1080p30, 1080i50, 1080i59.94 and 1080i60SD: 625/25 PAL, 525/29.97 NTSC, 525/23.98 NTSC |
| Playback Media Formats | GFX: JPEG or PNG image files with transparency support
DDR: AVI MJPEG with uncompressed audio, DV Video, WMV (7/8/9), H.264 (.mov &.avi), MPEG4 Part 2 (.mov & .avi), MPEG4 V1/V2 (.mov & .avi), AAC, MP3 |
| Record Media Formats | AVI MJPEG with uncompressed audio |
| Operating System | Windows 7 Professional (64-bit) |
| CPU | Intel Sandy Bridge-E Core i7 3930K 3.2 GHz Six-Core processor, 12 MB L3 cache, 130 W, Socket LGA 2011 |
| Graphics Card | Nvidia GeForce GT 520 Commercial Series PCI Express graphics card |
| Storage | 2 TB / 5,400 RPM / SATA 3.5" internal hard drive |
| RAM | 8 GB DDR3 1,333 MHz RAM (non-ECC )
(2 GB x 4 DIMM triple-channel configuration) |
| Processing | Video: 4:2:2, 10-bit Color (REC 601, REC 709)
Audio: 48 kHz, 24-bitREF IN/Genlock (Requires genlocking the 2 Blackmagic Design cards via 2 separate connectors) |
| Built-In Video Input/Output Cards | Blackmagic Design DeckLink Quad (PCI)
Blackmagic Design DeckLink Studio (PCI) |
| Dimensions | 20.00 x 16.50 x 5.25" (508.00 x 419.10 x 133.35 mm) (without including side rails) |
| Weight | Approximately 42 lb (19 kg) |
